Android App Analysis

Static and dynamic analysis of Android applications, from pulling the APK off a device through decompiling Smali, inspecting the manifest, and dumping runtime state.

Getting the APK

If the app is in the Play Store, the lazy way is to install it on a device and pull it off:

adb shell pm list packages | grep target
adb shell pm path com.target.app
# package:/data/app/.../base.apk

adb pull /data/app/~~hash~~/com.target.app-xxx/base.apk

If the app ships split APKs (most do now), pull all of them:

adb shell pm path com.target.app
# package:/data/app/.../base.apk
# package:/data/app/.../split_config.arm64_v8a.apk
# package:/data/app/.../split_config.en.apk
# package:/data/app/.../split_config.xxhdpi.apk

# Pull each, or merge into a single APK with apkeditor or apkmirror tools

If the app is not in the store, the client should provide a build. If they will not, that is itself a finding worth raising.

First Pass: The Manifest

The manifest tells you the attack surface in two minutes.

apktool d base.apk -o target/
cat target/AndroidManifest.xml

What I look for, in order:

android:debuggable="true", free game if present
android:allowBackup="true", lets you adb backup the app data
android:networkSecurityConfig, points to the cleartext and pinning config
Exported components, anything with android:exported="true" and no permission is reachable from any app on the device
Custom permissions, sometimes apps define a permission then forget to use it
Deep links, look for <intent-filter> with <data> elements
Custom URL schemes

Quick command for exported components:

grep -E 'android:exported="true"' target/AndroidManifest.xml

Decompiling

Two tools, two purposes.

apktool, for resources and Smali

apktool d base.apk -o target/
# target/smali/        - Smali assembly
# target/res/          - Resources
# target/AndroidManifest.xml

Smali is ugly to read but it is the ground truth. When jadx output is wrong (and it sometimes is), Smali is what is actually running.

jadx, for readable Java

jadx -d jadx-out base.apk
# or interactively
jadx-gui base.apk

jadx-gui is what I open first. Search across the decompiled source, jump to definitions, watch the call graph build out.

Useful searches in jadx

OkHttpClient and CertificatePinner, find SSL pinning
BuildConfig, hardcoded API URLs and keys
getSharedPreferences, local storage usage
Cipher.getInstance, crypto choices
Log.d and Log.e, what gets logged
Intent.parseUri, deep link handlers

Static Analysis Targets

Hardcoded secrets

# Search the unpacked resources and Smali
grep -r "api_key\|apiKey\|secret\|token\|password" target/
# Search strings in the original APK
strings base.apk | grep -i "api\|key\|secret"

# Filter by the app's PID
adb shell pidof com.target.app
adb logcat --pid=$(adb shell pidof com.target.app)

# Or filter by tag
adb logcat -s TargetApp:V

Inspect storage

adb shell run-as com.target.app
ls -la /data/data/com.target.app/
# shared_prefs/  databases/  files/  cache/
cat shared_prefs/prefs.xml
sqlite3 databases/main.db

If run-as does not work (release build), you need root.

Intercept traffic

Configure Burp or mitmproxy as the device proxy, push the CA into the system store (see Mobile Pentesting Fundamentals), and start the app. If pinning is in place, see SSL Pinning Bypass.

Trigger exported components

# Exported activity
adb shell am start -n com.target.app/.HiddenActivity

# Exported activity with extras
adb shell am start -n com.target.app/.WebViewActivity -e url "https://attacker.com"

# Exported service
adb shell am startservice -n com.target.app/.BackgroundService

# Broadcast receiver
adb shell am broadcast -a com.target.app.RECEIVE_DATA --es payload "evil"

# Content provider
adb shell content query --uri content://com.target.app.provider/users

Modifying the App

When hooking is not enough and you need to actually patch the binary:

# Decompile
apktool d base.apk -o target/

# Edit Smali in target/smali/...
# Common edit: change `const/4 v0, 0x0` (false) to `const/4 v0, 0x1` (true)

# Rebuild
apktool b target/ -o patched.apk

# Sign
keytool -genkey -v -keystore my.keystore -alias mykey -keyalg RSA -keysize 2048 -validity 10000
apksigner sign --ks my.keystore patched.apk

# Install
adb install -r patched.apk

This is heavy-handed. I prefer Frida hooks first, patching second.

Common Findings

Finding	How I look for it
Hardcoded API keys	grep on `BuildConfig` and strings
Insecure data storage	`shared_prefs`, `databases`, file mode `MODE_WORLD_READABLE`
Exported activity bypasses login	List exported activities, launch them directly
Deep link XSS or open redirect	Find `Intent.parseUri`, test with crafted URIs
WebView with file access	Search for `setAllowFileAccess(true)` or `setJavaScriptEnabled(true)`
Insecure broadcast receivers	Exported receivers handling sensitive intents
Tapjacking	Activities without `filterTouchesWhenObscured`
